Hup C 40-30 Special Application Crane

Combine the features and maneuverability of a crawler chassis with the quality and performance of a Potain self-erecting crane.

Easy transport and installation

Greatest versatility for large jobsites

Performance

  • 4 t (8,800 lb) Maximum capacity
  • 40 m (131 ft) jib radius
  • 1 t capacity at 40 m radius (2,200 lb at 131 ft)
  • 30 m (100 ft) HUH (Height Under Hook)
  • High Performance Slewing
  • Permanently reeved with 4 falls of rope
  • Ultimate jobsite versatility: 16 configurations

The Hup C 40-30 Special Application Crane allows the opportunity to work on more jobsites, such as, bridges, highway walls, and large jobsites that require the crane to move regularly

Compact crane

  • Transportation: very compact folded position:
    • 13,5 m (44.3 ft) long
    • 2,55 m (8.4 ft ) wide
    • ONLY 3,7 m (12.1 ft) tall
  • On-site footprint:
    • 5 m x 4,5 m (16.4 ft x 14.8 ft) base
    • WITH a 40 m (131 ft) jib radius
  • Easy offload crawling the crane directly from the trailer to the jobsite: no assist crane needed

Industry proven Hup crane installation

Erect the crane in under 20 minutes:

  • Once in position, the crane has hydraulic leveling
  • Smart Set-up software and exclusive Potain wireless remote control
  • Telescopic mast with 2 working positions: 25,6 m or 30 m (86 ft or 101 ft) HUH (height under hook)
  • 3 jib positions available: horizontal, 10°, 20°

Crawl the crane both in transport mode AND erected

  • Transport with crane folded: 25 m/min (82 fpm)
    • Front leveling up to 30% grade
    • Side leveling up to 12% grade
  • Transport with crane erected: 10 m/min (33 fpm)
    • Up to 5% front and side grade
  • Exclusive embedded power generator "Powerpack":
    • EPA Tier4 / EU stage V
    • Provides power for both the crawler hydraulic functionalities and the cranes electrical power needs

Hup C 40-30 Video and Data

Learn more by watching the video and downloading the datasheets below:
Hup C 40-30 Data Sheet - Imperial
Hup C 40-30 Data Sheet - Metric

Contact your local dealer today!

Hup C 40-30 Special application crane video
