GMK4100L-2

PERFECT ALL-ROUNDER

The Grove GMK4100L-2 combines compact design with superior strength. It offers impressive load charts and compact dimensions with a narrow width of 2.55 m. In the taxi configuration with 6.8 t on board, it offers the best load charts in its class. The remaining counterweight needed to reach full capacity fits on just one standard trailer. The latest EUROMOT 5 engine technology reduces fuel consumption and allows the use of 100% HVO fuel. The new driver's cab scores with the best comfort and ergonomics for the crane driver.

Features

  • New Grove carrier cab


  • GROVE® CONNECT™

    GROVE CONNECT IMAGE

    Our cranes become a connected and sustainable lifting solution.

    GROVE® CONNECT™

  • MEGATRAK®


    All wheels with independent hydropneumatic suspension and hydraulic lockout.

    Learn more

  • MAXbase™

    Grove MAXbase™

    Grove MAXbase™ allows asymmetrical outrigger positions

    MAXbase™

  • CRANIMAX® CRANEbee®

    CRANEbee® is a tool for lift planning that allows you to insert your cranes into a construction site environment using realistic and interactive 3D crane models.

    CRANIMAX® CRANEbee®
GROVE | All-Terrain Cranes

GMK4100L-2

  • Nominal capacity 115USt 100t
  • Total gross vehicle weight 105820lbs 48000kg
  • Main boom length 197ft 60m
  • Max tip height 292ft 89m
GMK4100L-2-silhouette-transparent-800x600.png Open gallery

Specifications

  • BOOM
    • Main boom:  11,3 m - 60 m, 7-section
    • MEGAFORM®
    • TWIN-LOCK®
    • Swingaway jib: 9,7 m /16 m (optional)
    • Boom extension: 1 x 8 m (optional)
  • CARRIER
    • Drive/steer: 8x6x8 (optional 8x8x8)
    • MEGATRAK®
    • Engine: Mercedes-Benz OM470LA, 320kW
    • Transmission: Mercedes G 280-16
    • EUROMOT 5 / EPA / CARB Tier 4 final (non-road) (optional EUROMOT 3a / EPA / CARB Tier 3 (non-road))
    • Carrier cab: Latest generation of Grove carrier cabs
  • SUPERSTRUCTURE
    • 20° Tiltable superstructure cab
    • Eco Mode
    • CCS (Crane Control System)
  • COUNTERWEIGHT
    • Total 26,0 t (6,8 t within 12 t/axle, 21,2 t within 16,5 t/axle, 21,2 t within vehicle width)
  • DIMENSIONS
    • Compact dimensions: Minimum width 2,55 m and overall length 13,21 m
    • Tailswing: 3,9 m
    • Outrigger base: 8,7 m x 7,2 m
    • MAXbase (optional)
